6 Drive Programming Commands
6 - 22
Drive Programming User’s Manual (I580-E2)
 A program example in which the condition to end the wait state is set in
<condition>: the program waits until the condition is met.
Flowchart Text
Block number Operation
1 Waits until X(00) changes to 1.
2 to 3 Adds 1 to U(00) and jumps to the block 1: loop_ unconditionally.
