Omron 3G3RX Series - Page 168

7 - 3
7 Precautions for Use of Parameters for Drive Programming
Drive Programming User’s Manual (I580-E2)
7-1 Inverter Parameters Affected by Setting Order
7
b063 Window Comparator FI Upper Limit Level Set an upper limit level.
Setting range: 0. to 100.
Lower limit: Lower limit level (b064)  Hysteresis
width (b065) x 2
b064 Window Comparator FI Lower Limit Level Set a lower limit level.
Setting range: 0. to 100.
Upper limit: Upper limit level (b063)  Hysteresis
width (b065) x 2
b065 Window Comparator FI Hysteresis Width Set a hysteresis width for the upper and lower limit
levels.
Setting range: 0. to 10.
Upper limit: (Upper limit level (b063)  Lower limit
level (b064)) /2
b066 RX only: Window Comparator FE Upper Limit
Level
Set an upper limit level.
Setting range: 100. to 100.
Minimum value: Lower limit level (b067)  Hystere-
sis width (b068)  2
b067 RX only: Window Comparator FE Lower Limit
Level
Set a lower limit level.
Setting range: 100. to 100.
Maximum value: Upper limit level (b066)  Hystere-
sis width (b068)  2
b068 RX only: Window Comparator FE Hysteresis
Width
Set a hysteresis width for the upper and lower limit
levels.
Setting range: 0. to 10.
Maximum value: (Upper limit level (b066)  Lower
limit level (b067)) /2
b100 Free V/f Frequency 1 0. to Free V/f Frequency 2 (b102)
b102 Free V/f Frequency 2 0. to
Free V/f Frequency 3 (b104)
b104 Free V/f Frequency 3 0. to Free V/f Frequency 4 (b106)
b106 Free V/f Frequency 4 0. to Free V/f Frequency 5 (b108)
b108 Free V/f Frequency 5 0. to Free V/f Frequency 6 (b110)
b110 Free V/f Frequency 6 0. to Free V/f Frequency 7 (b112)
b112 Free V/f Frequency 7 0. to 400.
Parameter
No.
Description Data
