Omron 3G3RX Series User Manual

5 - 15
5 Drive Programming User Variables
Drive Programming User’s Manual (I580-E2)
5-5 Inverter Monitor Variables
5
Use this function to monitor the output torque. The monitored data is equivalent to the data of the Out-
put Torque Monitor (d012). This variable is read-only.
Use this function to monitor the output voltage. The monitored data is equivalent to the data of the Out-
put Voltage Monitor (d013). This variable is read-only.
Use this function to monitor the input power. The monitored data is equivalent to the data of the Input
Power Monitor (d014). This variable is read-only.
Use this function to monitor the total operation time. The monitored data is equivalent to the data of the
Total RUN Time Monitor (d016). This variable is read-only.
Use this function to monitor the total power ON time. The monitored data is equivalent to the data of the
Total Power ON Time Monitor (d017). This variable is read-only.
The Drive Programming's user monitor variables UMon(0) to UMon(2) are the signed 2-word variables.
If any data is set in the user monitor variables UMon(0) to UMon(2) in the Drive Programming program,
the data can be displayed through the inverter's user monitor parameters (d025, d026 and d027). Use
this function to externally display the calculation status of the program.
Use this function to monitor the current position. The monitored data is equivalent to the data of the
Current Position Monitor (d030).
*1. The range of display shown in ( ) is for RX only.
This range of display is used when the V2 Control Mode Selection (P012) is set to 03 (HAPR: High-resolution
absolute position control mode).
Function
variable
Description Data range
Default
data
Unit Data size R/W
Tmon Output Torque Monitor
(d012)
200 to 200  % Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
Vout Output Voltage Monitor
(d013)
0 to 6,000  0.1 V Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
Power Input Power Monitor
(d014)
0 to 9,999  0.1 kW Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
RUN-Time Total RUN Time Monitor
(d016)
0 to 999,999  Time Unsigned
2 words
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
ON-Time Total Power ON Time
Monitor (d017)
0 to 999,999  Time Unsigned
2 words
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
UMon(0) to
UMon(2)
User Monitor 0 to 2
(d025 to d027)
2,147,483,647 to
2,147,483,647
0  Signed
2 words
R/W
Function
variable
Description Data range
Default
data
Unit Data size R/W
POS Current Position Monitor
(d030)
268,435,455 to
268,435,455
(  1,073,741,823 to
1,073,741,823)
*1
 1 Signed
2 words
R
