EN-30
U1-08 Output power in kW
U1-09 Torque reference in % of the motor rated torque
U1-10
Input terminal
status
Shows input ON/OFF status.
U1-11
Output termi-
nal status
Shows output ON/OFF status.
U1-12
Operation sta-
tus
Inverter operating status.
U1-13 Cumulative operation time
U1-20 Frequency reference after soft-starter
U1-34 OPE fault parameter
U1-51 Max Current during acceleration
U1-52 Max Current during deceleration
U1-53 Max Current during Top speed
U1-54 Max Current during leveling speed
U1-55 Number of travels
Fault Trace Data
U2-01 Current fault
U2-02 Last fault
U2-03 Reference frequency at fault
U2-04 Output frequency at fault
U2-05 Output current at fault
U2-06 Motor speed at fault
U2-07 Output voltage reference at fault
U2-08 DC bus voltage at fault
U2-09 Output power at fault
U2-10 Torque reference at fault
U2-11 Input terminal status at fault
U2-12 Output terminal status at fault
Param.
Num.
Name Description
1: FWD command
(S1) is ON
1: REV command
(S2) is ON
1: Multi input 1
(S3) is ON
1: Multi input 2
(S4) is ON
1: Multi input 3
(S5) is ON
1: Multi input 4
(S6) is ON
1: Multi input 5
(S7) is ON
1: Multi-function
contact output 1
(M1-M2) is ON
1: Multi-function
contact output 2
(M3-M4) is ON
1: Multi-function
contact output 3
(M5-M6) is ON
Not used
(Always 0).
1: Error output
(MA/MB-MC) is
ON
Run
1: Zero speed
1: Reverse
1: Reset signal
input
1: Speed agree
1: Inverter ready
1: Minor fault
1: Major fault
U2-13 Operation status at fault
U2-14 Cumulative operation time at fault
Fault History Data
U3-01
to
U3-04
Last fault to Fourth last fault
U3-05
to
U3-08
Cumulative operation time at fault 1 to 4
U3-09
to
U3-14
Fifth last to tenth last fault
U3-15
to
U3-20
Accumulated time of fifth to tenth fault
* The following errors are not recorded in the error log:
CPF00, 01, 02, 03, UV1, and UV2.
Digital Input Function Selections
3 Multi-step speed reference 1
4 Multi-step speed reference 2
6
Jog frequency command (higher priority than multi-step
speed reference)
F Not used (Set when a terminal is not used)
14 Fault reset (Reset when turned ON)
20 to
2F
External fault; Input mode: NO contact/NC contact, Detec-
tion mode: Normal/during operation
80 Nominal Speed Selection (d1-09)
81 Intermediate Speed Selection (d1-10)
82 Releveling Speed Selection (d1-13)
83 Leveling Speed Selection (d1-17)
84 Inspection Run Selection (d1-14)
Digital Output Function Selections
0
During run 1 (ON: run command is ON or voltage is being
output)
6
Inverter operation ready; READY: After initialization or no
faults
8 During baseblock (NO contact, ON: during baseblock)
B
Car stuck/undertorque detection 1 NO (NO contact, ON:
Overtorque/undertorque detection)
F Not used. (Set when the terminal is not used.)
10 Minor fault (ON: Alarm displayed)
17
Car stuck/undertorque detection 1 NC (NC Contact, OFF:
Torque detection)
1A During reverse run (ON: During reverse run)
40 Brake Release Command
41 Output Contactor Close Command
Param.
Num.
Name Description
