Appendices
A-58
CP1E CPU Unit Software User’s Manual(W480)
A283 00 PWM Output 0
Output In-progress
Flag
ON when pulses are being output from
PWM output 0.
• Cleared when operation starts or
stops.
OFF: Stopped
ON: Outputting pulses.
Cleared Refreshed
when pulse
output starts or
stops.
A294 Task Number when
Program Stopped
This word contains the task number of
the task that was being executed when
program execution was stopped
because of a program error.
Note A298 and A299 contain the pro-
gram address where program
execution was stopped.
Cyclic tasks: 0000
Interrupt tasks: 8000
to 800F (task 0 to 15)
Cleared Cleared When pro-
gram error
occurs.
A298/
A299
A295 08 Instruction Processing
Error Flag
This flag and the Error Flag (ER) will be
turned ON when an instruction pro-
cessing error has occurred and the
PLC Setup has been set to stop opera-
tion for an instruction error. CPU Unit
operation will stop and the ERR/ALM
indicator will light when this flag goes
ON.
Note The task number where the error
occurred will be stored in A294
and the program address will be
stored in A298 and A299.
ON: Error Flag ON
OFF: Error Flag OFF
Cleared Cleared When pro-
gram error
occurs.
A294,
A298/
A299
PLC
Setup
(Opera-
tion when
instruc-
tion error
has
occurred)
09 Indirect DM BCD Error
Flag
This flag and the Access Error Flag
(AER) will be turned ON when an indi-
rect DM BCD error has occurred and
the PLC Setup has been set to stop
operation an indirect DM BCD error.
(This error occurs when the content of
an indirectly addressed DM word is not
BCD although BCD mode has been
selected.) CPU Unit operation will stop
and the ERR/ALM indicator will light
when this flag goes ON.
Note The task number where the error
occurred will be stored in A294
and the program address will be
stored in A298 and A299.
ON: Not BCD
OFF: Normal
Cleared Cleared When pro-
gram error
occurs.
A294,
A298/
A299
PLC
Setup
(Opera-
tion when
instruc-
tion error
has
occurred)
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
