A
A-1 Channel/Relay Numbers
SYSMAC CP1L Getting Started Guide 99
Appendix
zClock Pulses
Clock pulses are contacts that turn ON/OFF at a fixed time interval.
Note To enter a clock pulse or condition flag into CX-Programmer, first enter a contact,
then press the [P] key to select from the drop-down list.
Name Label In CX-P Function
0.02s clock pulse 0.02s P_0.02s
0.1s clock pulse 0.1s P_0.1s
0.2s clock pulse 0.2s P_0.2s
1.0s clock pulse 1s P_1s
1min clock pulse 1min P_1min
0.02s
0.01s 0.01s
0.1s
0.05s 0.05s
0.2s
0.1s 0.1s
1.0s
0.5s 0.5s
1min
30s 30s
W07E-EN-02+CP1L+GettingStartedGuide.book Seite 99 Montag, 15. September 2008 11:15 11
