A-4 CP1L Programming Examples
SYSMAC CP1L Getting Started Guide 139
Appendix
 System Configuration
zWiring Example
*Insert a resistance of 1.6 to 2.2k , so that the current is within the 7 to 15mA
range.
*For a 20/30/40-point CPU, the origin proximity input (pulse 0) will be 0CH10bit.
CCW limit
sensor
0.00
Origin proximity
sensor
0.02
Start
origin search
0.03
24VDC
+
Positioning
to point A
0.04 0.05
1.6k Ω
(*)
CW
output
100.00
CCW
outpput
100.01
Error counter
reset output
100.04
NO
contact
Origin search
complete
100.05
Point A
positioning
complete
100.02 100.03
1
CW
2CW
3 CCW
4 CCW
8 ECRST
9 ECRST
5 24V IN
6
10
11
FG
CN1
NO
contact
NO
contact
CW
li
m
it
sensor
0.01
Positioning
to point B
–
Point B
positioning
complete
RUN
Z
ZCOM
R7D series
CP1L-L14DT
(*)
(*)
Indicator
+
-
Hood
W07E-EN-02+CP1L+GettingStartedGuide.book Seite 139 Montag, 15. September 2008 11:15 11
