A-4 CP1L Programming Examples

142 SYSMAC CP1L Getting Started Guide

Appendix

zDM Area Setup Example

Address Value Content

Point A

positioning

D0000 07D0 Acceleration ratio: 2000 (Hz/4ms)

D0001 07D0 Deceleration ratio: 2000 (Hz/4ms)

D0002 C350 Target frequency: 50000 (Hz)

D0003 0000

D0004 FC18 Pulse output volume: -1000 (Hz)

D0005 FFFF

Initial

frequency

D0006 0000 Initial frequency: 0 (Hz)

D0007 0000

Point B

positioning

D0010 07D0 Acceleration ratio: 2000 (Hz/4ms)

D0011 07D0 Deceleration ratio: 2000 (Hz/4ms)

D0012 C350 Target frequency: 50000 (Hz)

D0013 0000

D0014 86A0 Pulse output volume: 100000 (Hz)

D0015 0001
