4-4 Using the Help
4
4
52 SYSMAC CP1L Getting Started Guide
Creating Programs
zFrom CX-Programmer
1. Select [Help] - [Instruction Reference] - [CS/CJ-Series and CP-Series]
from the main menu.
CP-Series PLC Instruction Sets will be displayed.
zWhile Creating Ladder Programs
1. While creating a ladder program instruction, click [Instruction Help] on
the New Instruction dialog box.
CP-Series PLC Instruction Sets will be displayed.
Note When selecting a special instruction, Instruction Help will be displayed.
