Allocations to Slave Units Section 5-2
1 Special I/O Unit Area
Words +0
to
+15
Output data (16 words)
Word Slave Unit outputs 0 to 15
Words +16
to
+31
Input data (16 words)
Word Slave Unit inputs 0 to 15
Word +32 Status (1 word)
Word +33 Parameter settings (1 word)
Words +34
to
+37
Participation Flags and Communications Error
Flags (4 words)
Words +38
+39
Not used (2 words)
2 Special I/O Unit Area
Words +0
to
+31
Output data (32 words)
Word Slave Unit outputs 0 to 31
Words +32
to
+63
Input data (32 words)
Word Slave Unit inputs 0 to 31
Word +64 Status (1 word)
Word +65 Parameter settings (1 word)
Words +66
to
+73
Participation Flags and Communications Error
Flags (8 words)
Words +74
to
+79
Not used (6 words)
Communications
mode number
Pattern
