114
Allocations to Slave Units Section 5-2
3 Special I/O Unit Area
Words +0
to
+15
Output data (16 words)
Word Slave Unit outputs 0 to 15
Words +16
to
+31
Input data (16 words)
Word Slave Unit inputs 0 to 15
Words +32
to
+39
Bit output data (8 words)
Bit Slave Unit outputs: 0 to 63
Words +40
to
+47
Bit input data (8 words)
Bit Slave Unit inputs: 0 to 63
Word +48 Status (1 word)
Word +49 Parameter settings (1 word)
Words +50
to
+53
Participation Flags and Communications Error
Flags (4 words)
Words +54
to
+69
Bit Slave Participation Flags and Communica-
tions Error Flags (16 words)
Words +70
to
+79
Not used (10 words)
Communications
mode number
Pattern
