116
Allocations to Slave Units Section 5-2
Allocating Two Unit
Numbers per Node
(Communications Mode 0)
CIO 2000 + (10 × unit No.) to CIO 2019 + (10 × unit No.): Unit No. = 0 to 94
Allocating Four Unit
Numbers per Node
(Communications Mode 1)
CIO 2000 + (10 × unit No.) to CIO 2039 + (10 × unit No.): Unit No.= 0 to 92
First
allocated
word
Unit number setting
CIO 2000 Unit No. 0
CIO 2010 Unit No. 1
CIO 2020 Unit No. 2
CIO 2030 Unit No. 3
CIO 2040 Unit No. 4
CIO 2050 Unit No. 5
CIO 2060 Unit No. 6
CIO 2070
:
CIO 2920 Unit No. 92
CIO 2930 Unit No. 93
CIO 2940 Unit No. 94
CIO 2950
First
allocated
word
Unit number setting
CIO 2000 Unit No. 0
CIO 2010 Unit No. 1
CIO 2020 Unit No. 2
CIO 2030 Unit No. 3
CIO 2040 Unit No. 4
CIO 2050 Unit No. 5
CIO 2060 Unit No. 6
CIO 2070 Unit No. 7
CIO 2080
CIO 2090
CIO 2100
:
CIO 2890 Unit No. 89
CIO 2900 Unit No. 90
CIO 2910 Unit No. 91
CIO 2920 Unit No. 92
CIO 2930
CIO 2940
CIO 2950
