122
Allocations to Slave Units Section 5-2
• Sixteen-point Input Slave Unit + Eight-point Input Expansion Unit
Two node address areas are allocated: Node address m and node address
m+1 in the IN area.
• Sixteen-point Input Slave Unit + Sixteen-point Expansion Output Unit
Two node address areas are allocated: Node address m in the IN area and
node address m in the OUT area.
• Sixteen-point Input Slave Unit + Eight-point Expansion Output Unit
Two node address areas are allocated: Node address m in the IN area and
node address m in the OUT area.
• Sixteen-point Output Slave Unit + Sixteen-point Expansion Output Unit
Two node address areas are allocated: Node address m and node address
m+1 in the OUT area.
• Sixteen-point Output Slave Unit + Eight-point Expansion Output Unit
Two node address areas are allocated: Node address m and node address
m+1 in the OUT area.
IN area
123456789101112131415 0
17181920212223 16
Unused
OUT area
123456789101112131415 0
IN area
123456789101112131415 0
OUT area
12345670
IN area
123456789101112131415 0
Unused
OUT area
123456789101112131415 0
171819202122232425262728293031 16
OUT area
123456789101112131415 0
17181920212223 16
Unused
