125
Allocations to Slave Units Section 5-2
Bit Output Data Allocations
• Two-point Input Slave Unit
• Four-point Input Slave Unit
• Two-point Output Slave Unit
• Four-point Mixed Slave Unit
In Bit Slave Units, the node address area is used consecutively without
spaces. For example, one word would be allocated for eight Slave Units each
with two points. Likewise, one word would be allocated for four sets of Slave
Units each with two points and two Slave Units each with four points.
Bits
Word
address
1514131211109876543210
+0 BIT OUT7 BIT OUT6 BIT OUT5 BIT OUT4 BIT OUT3 BIT OUT2 BIT OUT1 BIT OUT0
+1 BIT OUT15 BIT OUT14 BIT OUT13 BIT OUT12 BIT OUT11 BIT OUT10 BIT OUT9 BIT OUT8
+2 BIT OUT23 BIT OUT22 BIT OUT21 BIT OUT20 BIT OUT19 BIT OUT18 BIT OUT17 BIT OUT16
+3 BIT OUT31 BIT OUT30 BIT OUT29 BIT OUT28 BIT OUT27 BIT OUT26 BIT OUT25 BIT OUT24
+4 BIT OUT39 BIT OUT38 BIT OUT37 BIT OUT36 BIT OUT35 BIT OUT34 BIT OUT33 BIT OUT32
+5 BIT OUT47 BIT OUT46 BIT OUT45 BIT OUT44 BIT OUT43 BIT OUT42 BIT OUT41 BIT OUT40
+6 BIT OUT55 BIT OUT54 BIT OUT53 BIT OUT52 BIT OUT51 BIT OUT50 BIT OUT49 BIT OUT48
+7 BIT OUT63 BIT OUT62 BIT OUT61 BIT OUT60 BIT OUT59 BIT OUT58 BIT OUT57 BIT OUT56
+8 BIT OUT71 BIT OUT70 BIT OUT69 BIT OUT68 BIT OUT67 BIT OUT66 BIT OUT65 BIT OUT64
+9 BIT OUT79 BIT OUT78 BIT OUT77 BIT OUT76 BIT OUT75 BIT OUT74 BIT OUT73 BIT OUT72
+10 BIT OUT87 BIT OUT86 BIT OUT85 BIT OUT84 BIT OUT83 BIT OUT82 BIT OUT81 BIT OUT80
+11 BIT OUT95 BIT OUT94 BIT OUT93 BIT OUT92 BIT OUT91 BIT OUT90 BIT OUT89 BIT OUT88
+12 BIT
OUT103
BIT
OUT102
BIT
OUT101
BIT
OUT100
BIT OUT99 BIT OUT98 BIT OUT97 BIT OUT96
+13 BIT
OUT111
BIT
OUT110
BIT
OUT109
BIT
OUT108
BIT
OUT107
BIT
OUT106
BIT
OUT105
BIT
OUT104
+14 BIT
OUT119
BIT
OUT118
BIT
OUT117
BIT
OUT116
BIT
OUT115
BIT
OUT114
BIT
OUT113
BIT
OUT112
+15 BIT
OUT127
BIT
OUT126
BIT
OUT125
BIT
OUT124
BIT
OUT123
BIT
OUT122
BIT
OUT121
BIT
OUT120
Bit IN area
10
Bit IN area
1230
Bit OUT area
10
Bit OUT area
Bit IN area
1
10
0
