Allocations to Slave Units Section 5-2
Note Word +0 is assumed to be the first word of the memory allocated for Special
I/O Units, i.e., CIO 2000 + (10 × unit number).
+59 Bit Input Slave Unit Communica-
tions Error Flags (16 to 23)
Bit Input Slave Unit Participation
Flags (16 to 23)
+60 Bit Output Slave Unit Communica-
tions Error Flags (24 to 31)
Bit Output Slave Unit Participation
Flags (24 to 31)
+61 Bit Input Slave Unit Communica-
tions Error Flags (24 to 31)
Bit Input Slave Unit Participation
Flags (24 to 31)
+62 Bit Output Slave Unit Communica-
tions Error Flags (32 to 39)
Bit Output Slave Unit Participation
Flags (32 to 39)
+63 Bit Input Slave Unit Communica-
tions Error Flags (32 to 39)
Bit Input Slave Unit Participation
Flags (32 to 39)
+64 Bit Output Slave Unit Communica-
tions Error Flags (40 to 47)
Bit Output Slave Unit Participation
Flags (40 to 47)
+65 Bit Input Slave Unit Communica-
tions Error Flags (40 to 47)
Bit Input Slave Unit Participation
Flags (40 to 47)
+66 Bit Output Slave Unit Communica-
tions Error Flags (48 to 55)
Bit Output Slave Unit Participation
Flags (48 to 55)
+67 Bit Input Slave Unit Communica-
tions Error Flags (48 to 55)
Bit Input Slave Unit Participation
Flags (48 to 55)
+68 Bit Output Slave Unit Communica-
tions Error Flags (56 to 63)
Bit Output Slave Unit Participation
Flags (56 to 63)
+69 Bit Input Slave Unit Communica-
tions Error Flags (56 to 63)
Bit Input Slave Unit Participation
Flags (56 to 63)
Word
(See
note.)
Bits
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
