Allocations to Slave Units Section 5-2
Communications Mode 8
■ Word Slave Participation Flags and Communications Error Flags
Note Word +0 is assumed to be the first address set under Status on the Master I/O
Allocation Tab Page in the software setting by the CX-Integrator.
Word
(See
note.)
Bit
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
+0 Word Output Slave Unit Communi-
cations Error Flags (0 to 7)
Word Output Slave Unit Participa-
tion Flags (0 to 7)
+1 Word Input Slave Unit Communica-
tions Error Flags (0 to 7)
Word Input Slave Unit Participation
Flags (0 to 7)
+2 Word Output Slave Unit Communi-
cations Error Flags (8 to 15)
Word Output Slave Unit Participa-
tion Flags (8 to 15)
+3 Word Input Slave Unit Communica-
tions Error Flags (8 to 15)
Word Input Slave Unit Participation
Flags (8 to 15)
+4 Word Output Slave Unit Communi-
cations Error Flags (16 to 23)
Word Output Slave Unit Participa-
tion Flags (16 to 23)
+5 Word Input Slave Unit Communica-
tions Error Flags (16 to 23)
Word Input Slave Unit Participation
Flags (16 to 23)
+6 Word Output Slave Unit Communi-
cations Error Flags (24 to 31)
Word Output Slave Unit Participa-
tion Flags (24 to 31)
+7 Word Input Slave Unit Communica-
tions Error Flags (24 to 31)
Word Input Slave Unit Participation
Flags (24 to 31)
+8 Word Output Slave Unit Communi-
cations Error Flags (32 to 39)
Word Output Slave Unit Participa-
tion Flags (32 to 39)
+9 Word Input Slave Unit Communica-
tions Error Flags (32 to 39)
Word Input Slave Unit Participation
Flags (32 to 39)
+10 Word Output Slave Unit Communi-
cations Error Flags (40 to 47)
Word Output Slave Unit Participa-
tion Flags (40 to 47)
+11 Word Input Slave Unit Communica-
tions Error Flags (40 to 47)
Word Input Slave Unit Participation
Flags (40 to 47)
+12 Word Output Slave Unit Communi-
cations Error Flags (48 to 55)
Word Output Slave Unit Participa-
tion Flags (48 to 55)
+13 Word Input Slave Unit Communica-
tions Error Flags (48 to 55)
Word Input Slave Unit Participation
Flags (48 to 55)
+14 Word Output Slave Unit Communi-
cations Error Flags (56 to 63)
Word Output Slave Unit Participa-
tion Flags (56 to 63)
+15 Word Input Slave Unit Communica-
tions Error Flags (56 to 63)
Word Input Slave Unit Participation
Flags (56 to 63)
