180
Error History Function Section 8-2
0107 Transmission is not possible because
remote node is not participating in the
network.
Response
Bit 15: ON
Bits 14 to 8: DNA
Bits 7 to 0: DA1
×
0108 Transmission is not possible because
there is no Unit corresponding to the
unit number.
×
0109 Transmission is not possible because
the remote node is busy.
×
010B Transmission is not possible because of
a PLC error.
×
010D Transmission is not possible because
no destination address is set in the
routing tables.
×
010E Transmission is not possible because
the routing tables are not registered.
×
010F Transmission is not possible because of
a routing table error.
Command
Bit 15: OFF
Bits 14 to 8: SNA
Bits 7 to 0: SA1
×
0110 Transmission is not possible because of
too many relays.
×
0111 Transmission is not possible because
the command exceeds the maximum
command length.
Response
Bit 15: ON
Bits 14 to 8: DNA
Bits 7 to 0: DA1
×
0112 Transmission is not possible because of
a header error.
×
0117 Packet was discarded because the
internal reception buffer was full.
×
0118 Illegal packet discarded ×
0120 Unexpected routing error ×
0122 Packet was discarded because it could
not be serviced in the current mode.
×
0123 Packet was discarded because the
internal buffer was full.
×
0124 Routing is not possible because the
maximum frame length was exceeded.
×
0125 Packet was discarded because of a
response timeout.
×
0300 Packet was discarded because of a
parameter error.
×
021A Setting table logic error 00 hex 01 hex: Network parameters
02 hex: Software Setting Table
03 hex: Routing Table
04 hex: System Setup
0A hex: Registration Table
❍
0347 I/O refresh error 00 hex 00 hex ×
0370 Verification error (non-existent Slave
Unit)
00 00 ×
0372 Verification error (unregistered Slave
Unit)
10 hex: Word Input Slave Unit,
Word I/O Slave Unit
20 hex: Word Output Slave
Unit
40 hex: Bit Input Slave Unit,
Bit I/O Slave Unit
50 hex: Bit Output Slave Unit
Node address (hex) ×
Error
code
(hex)
Error contents Detailed information EEP
ROM
First byte Second byte
