FINS Commands Addressed to CompoNet Master Units and Responses Appendix A
Resets (restarts) the CompoNet Master Unit.
A parameter can be added to restart at a specified baud rate.
Command Format for Resetting
Command Format for Resetting at a Specified Baud Rate
Response Format
Note No response is returned for a normal completion. A response is returned only when an error occurs.
End Codes (MRES/SRES)
Parameter Details
FLAG: Stores a value specifying the desired baud rate.
01 hex: Reset at 93.75 k.
02 hex: Reset at 1.5 M.
03 hex: Reset at 3 M.
04 hex: Reset at 4 M.
00/FF hex: Reset at baud rate set on DIP switch.
Description
RESET resets the CompoNet Master Unit.
No response is returned for a normal completion. A response is returned only when an error occurs.
This command is used to restore operation after resetting the Master Unit when a communications error has
occurred at a Slave Unit during I/O communications.
RESET 0403
MRC
04
SRC
03
1B 1B
MRC
04
SRC
03
FLAG
XX
1B 1B 1B
MRC
04
SRC
03
MRES SRES
1B 1B 1B 1B
End code (hex) Contents
1001 The maximum permissible command length was exceeded.
1004 There is an error in the command format.
250F A memory error occurred.
