FINS Commands Addressed to CompoNet Master Units and Responses Appendix A
Reads CompoNet Master Unit information.
Command Format
Response Format
End Codes (MRES/SRES)
Parameter Details
Model (Response)
The CompoNet Master Unit model number is returned in up to 20 bytes of ASCII.
The unused portion of the 20 bytes is padded with spaces (20 hex).
CJ1W-CRM21@@@@@@@@@@ (@: Space)
or
CS1W-CRM21@@@@@@@@@@ (@: Space)
Version (Response)
V1.00@@@@@@@@@@@@@@@ (@: Space)
Mode No.
The mode number set on the mode setting switch is returned.
0x00 to 0x09
DIP Switch
The DIP switch setting for five pins are returned.
0: OFF, 1: ON
READ CONTROLLER INFORMATION 0501
MRC
05
SRC
01
1B 1B
MRC
05
SRC
01
MRES SRES Model Version Mode
No.
DIP
Switch
1B 1B 1B 1B 20B 20B 1B 1B
End code (hex) Contents
0000 Normal completion
1001 The maximum permissible command length was exceeded.
D7 D6 D5 D4 D3 D2 D1 D0
Always 0. Always 0. Always 0. Always 0. REGS ESTP DR-H DR-L
