15
Devices in a CompoNet Network Section 1-3
■ Flat Cable II
Flat Connector Plug
■ Flat Cable I
Note Although this product is called a Flat Connector Plug, it can be
used as a connector to connect a Master Unit, Slave Unit, or Re-
peater Unit.
Name Model Appearance Application
Communications Cables
(Yes: Can be used.
No: Cannot be used.)
Round
Cable I
Round
Cable II
Flat
Cable I
Flat
Cable II
Flat Connector
Socket
DCN5-TR4 Use this Connector in a set with
a DCN5-BR4 Flat Connector
Plug for the following applica-
tions.
• Extending the trunk line or a
sub-trunk line
• T-branching from the trunk line
or a sub-trunk line
• T-branching a sub-branch line
from a branch line
Note Use the Connector to
connect IP54 Bit Slave
Units.
No No No Yes
Name Model Appearance Application
Communications Cables
(Yes: Can be used.
No: Cannot be used.)
Round
Cable I
Round
Cable II
Flat
Cable I
Flat
Cable II
Flat Connector
Plug
DCN4-BR4 a. Use the Connector in a set
with a DCN4-TR4 Flat Con-
nector Socket for the follow-
ing applications.
• Extending the trunk line or a
sub-trunk line
• T-branching from the trunk line
or a sub-trunk line
• T-branching a sub-branch line
from a branch line
b. Use this Connector indepen-
dently for the following appli-
cations.
• Connecting Communications
Cable to a Master Unit, Word
Slave Unit, or Repeater Unit
• Connecting Communications
Cable to a Multi-wiring Con-
nector
No No Yes No
