Omron E5CC-800 User Manual

Index-3
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
power supply ............................................................... 2-14
Protect Level ...............................................................A-19
R
ratings ...........................................................................A-2
RS-485 .................................................................2-17, A-4
S
sampling cycle .......................................................1-2, A-3
sensor input ................................................................ 2-11
sensor input setting ranges .........................................A-21
setting levels diagram .................................................A-22
Shift Key (S Key) ......................................................... 3-7
specifications ................................................................A-2
T
terminal arrangement .................................................... 2-6
terminal block wiring examples
E5CC ....................................................................... 2-6
E5EC ..................................................................... 2-10
troubleshooting .............................................................A-9
U
Up Key (U Key) ............................................................ 3-6
using the terminals ........................................................ 2-6
W
wiring .......................................................................... 2-14
wiring precautions ....................................................... 2-14

Omron E5CC-800 Specifications

General

Communication	RS-485 (optional)
Protection Rating	IP66 (front panel)
Input Type	Thermocouple, RTD, analog input
Output Type	Relay, voltage, current
Supply Voltage	100-240 VAC, 24 VAC/VDC
Size	48 x 48 mm
Control Output	Relay, voltage, current
Ambient Operating Temperature	55 °C
Control Method	ON/OFF, 2-PID
Ambient Operating Humidity	35 to 85% RH (non-condensing)
Mounting	Panel mount
