Omron E5CN User Manual

175
Adjustment Level Section 5-4
• This parameter sets the time for the control operation when using the sim-
ple program function.
■ Related Parameters
Program start, Soak time remain (operation level): Page 155
Wait band (adjustment level): Page 175
Program pattern (initial setting level): Page 189
Soak time unit (advanced function setting level): Page 224
• This parameter sets the stable band within which the soak time is mea-
sured for the simple program function.
Note Set “None” as the unit for Controllers with Analog Inputs.
■ Related Parameters
Program start, Soak time remain (operation level): Page 155
Soak time (adjustment level): Page 175
Program pattern (initial setting level): Page 189
Soak time unit (advanced function setting level): Page 224
soak Soak Time
The Program Pattern parameter
must not be set to OFF.
Setting range Unit Default
1 to 9999 min or h 1
Function
Setting
See
See
wt-b Wait Band
The Program Pattern parameter
must not be set to OFF.
Model Setting range Unit Default
Controllers with Thermocouple/Resis-
tance Thermometer Universal Inputs
OFF or 0.1 to
999.9
°C or °F
(See note.)
off
Controllers with Analog Inputs OFF or 0.01 to
99.99
%FS
Function
Setting
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
