176
Adjustment Level Section 5-4
• This parameter sets the MV to use when the RUN/STOP status changes
from RUN to STOP.
■ Related Parameters
RUN/STOP (operation level): Page 156
MV at stop and error addition (advanced function setting level): Page 214
• This parameter sets the MV to use when an input error occurs.
■ Related Parameters
MV at stop and error addition (advanced function setting level): Page 214
mv-s MV at Stop
The control must be set to 2-PID
control.
The MV at Stop and Error Addition
parameter must be ON.
Setting range Unit Default
−5.0 to 105.0 for standard control
−105.0 to 105.0 (heating/cooling control)
%0.0
Function
Setting
See
See
mv-e MV at PV Error
The control must be set to 2-PID
control.
The MV at Stop and Error Addition
parameter must be ON.
Setting range Unit Default
−5.0 to 105.0 for standard control
−105.0 to 105.0 (heating/cooling control)
%0.0
Function
Setting
See
See
To Next Page
