Omron E5CN User Manual

193
Initial Setting Level Section 5-7
Standby sequence reset: Page 202, Auxiliary output 1 to 3 open in alarm:
Page 203, Alarm 1 to 3 latch: Page 208 (advanced function setting level)
• Select one of the following four alarm 2 types:
Deviation, deviation range, absolute value, or PV change rate alarm.
Refer to the alarm 1 type list. The 12: LBA (Loop Burnout Alarm) setting in
that list cannot be used.
■ Related Parameters
Alarm value 2: Page 157, Alarm value upper limit 2, Alarm value lower limit 2:
Page 158 (operation level)
Standby sequence reset: Page 202, Auxiliary output * open in alarm: Page
203, Alarm 2 hysteresis: Page 192, Alarm 2 latch: Page 208 (advanced func-
tion setting level)
• Select one of the following four alarm 3 types:
Deviation, deviation range, absolute value, or PV change rate alarm.
Refer to the alarm 1 type list. The 12: LBA (Loop Burnout Alarm) setting in
that list cannot be used.
■ Related Parameters
Alarm value 3: Page 157, Alarm value upper limit 3, Alarm value lower limit 3:
Page 159 (operation level)
Standby sequence reset: Page 202, Auxiliary output * open in alarm: Page
203, Alarm 3 hysteresis: Page 192, Alarm 3 latch: Page 208 (advanced func-
tion setting level)
alt2 Alarm 2 Type
Alarm 2 must be assigned.
Function
Setting
See
See
alt3 Alarm 3 Type
Alarm 3 must be assigned.
Function
Setting
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
