223
Advanced Function Setting Level Section 5-8
• This parameter sets the function to be assigned to Auxiliary output 3.
Note (1) If c-o is assigned for standard control, a value equivalent to 0% will be
output.
(2) Can be selected when the Program Pattern parameter is set to OFF, but
the function will be disabled.
(3) If the Standard or Heating/Cooling parameter is set to heating/cooling
control when there is no control output 2 (E5AN/EN), control automatical-
ly switches to c-o.
(4) WR1 to WR8 are not displayed when the logic operation function is not
used.
■ Related Parameters
Standard or heating/cooling: Page 188, Program pattern: Page 189, (initial
setting level)
sub3 Auxiliary Output 3 Assignment
Auxiliary output 3 must be assigned
(E5AN and E5EN only).
Setting range Default
none: No function is assigned to auxiliary output 3. alm3
(See note
3.)
o: Heating control output is output.
c-o: Cooling control output is output. (See note 1.)
alm1: Alarm 1 is output.
alm2: Alarm 2 is output.
alm3: Alarm 3 is output.
p.end: Program end is output. (See note 2.)
ralm: Control output ON/Off count alarm
wr1: Work bit 1 (See note 4.)
wr2: Work bit 2 (See note 4.)
wr3: Work bit 3 (See note 4.)
wr4: Work bit 4 (See note 4.)
wr5: Work bit 5 (See note 4.)
wr6: Work bit 6 (See note 4.)
wr7: Work bit 7 (See note 4.)
wr8: Work bit 8 (See note 4.)
Function
Setting
See
See
