Omron E5CN User Manual

224
Advanced Function Setting Level Section 5-8
• This parameter switches the characters to be displayed.
The following two types of characters can be displayed.
11-segment display
7-segment display
When set to on, an 11-segment display is used.
• Set the soak time unit for the simple program function.
■ Related Parameters
Program start, Soak time remain (operation level): Page 155
Soak time, Wait band (adjustment level): Page 175
Program pattern (initial setting level): Page 189
csel Character Select
Setting range Default
on: 11-segment display, off: 7-segment display on
Function
Setting
t-u Soak Time Unit
The Program Pattern parameter
must not be set to OFF.
Setting range Default
m: Minutes, h: Hours m
Function
Setting
See
See

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
