Chapter4 Input/Output Circuit
F3SJ-E/B
User’s Manual
Input/Output Circuit and Applications
Input/Output Circuit

Easy Type
 Entire circuit diagram
The entire circuit diagram of the Easy Type is shown below.
 Input circuit diagram by function
The input circuit diagram of the Easy Type by function is shown below.
Emitter
Main Circuit
Indication
Receiver
Main Circuit 2
+24 VDC
Brown
Black
Test input
Blue
Brown
White
Safety output 2
Black
Safety output 1
Blue
PinkGray
Pink
Communication line (+)
0 V
Load
Load
Test Input
Circuit
Gray
Communication line (-)
Receiver
Main Circuit 1
Indication
Emitter
Main
Circuit
+24 VDC
0 V
Short circuit current 3 mA
<Input Circuit (Test Input)>
