Omron F3SJ-E0185P25 User Manual

96
Chapter4 Wiring Examples
F3SJ-E/B
User’s Manual
Input/Output Circuit and Applications
 Connecting a F3SJ-E to Various Controllers
 Connecting a F3SJ-E to a G9SA-301 Controller
Unblocked
Blocked
External test/lockout reset switch
(S1)
Interlock reset switch
(S2)
Emergency stop switch
(S3)
Safety output
K1,K2 N.O. contact
KM1,KM2 N.O. contact
K1,K2 N.C. contact
KM1,KM2 N.C. contact
Model G9SA-301
Safety output 1
(Black)
Safety output 2
(White)
0 V (Blue)
+24 V (Brown)
+24 V (Brown)
Communication
line (+) (Gray)
Communication
line (-) (Pink)
S1
0 V
A1 A2
T11 T12
S2
KM1
KM2
T31
- G9SA-301 settings
- Manual reset mode
- Using feedback loop
- Using emergency stop switch
K1
3
4
K2
1
a
b
2
5
T32
41
33
23
13
1
2
3
4
5
6
JP
6
a
b
K1
K2
K1
K2
PE T21
T23 T22
A
B
14 24 34 42
Control
Circuit
KM2
*1 If an emergency stop switch is not used, connect safety output 1 to
T12 terminal and safety output 2 to T23 directly.
S1 : External test/lockout reset switch
(connect to 0 V if a switch is not required)
S2 : Interlock reset switch
S3 :
Emergency stop switch (force-opening contact) (A165E, A22E)
KM1, KM2 : Safety relay with force-guided contact (G7SA) or
magnetic contactor
M : 3-phase motor
*1
11
12
21
22
S3
KM1
T32
T31
KM1
KM2
A B
Wiring for auto reset mode
Feedback loop
M
KM1
KM2
Emitter
Receiver
0 V (Blue)
Test input
(Black)
+24 VDC
Power
Supply
Feedback loop
