Omron F3SJ-E0185P25 User Manual

4
Chapter1 Internal (LED) Indicator Display Pattern
F3SJ-E/B
User’s Manual
Overview and Specifications
Internal (LED) Indicator Display Pattern
Emitter
Receiver
6. Test indicator (Green)
5. Power indicator (Green)
4. Lockout indicator (Red)
3. ON/OFF-state indicator (Green/Red)
2. Stable-state indicator (Green)
1. Top-beam-state indicator (Blue)
10. Bottom-beam-state indicator (Blue)
4. Lockout indicator (Red)
3. ON/OFF-state indicator (Green/Red)
2. Stable-state indicator (Green)
1. Top-beam-state indicator (Blue)
10. Bottom-beam-state indicator (Blue)
7. Internal error indicator (Red)
6. Configuration indicator (Green)
5. Communication indicator (Green)
Emitter
Receiver
10. Bottom-beam-state indicator (Blue)
9. Muting input 2 indicator (Green)
8. Muting input 1 indicator (Green)
7. Muting error indicator (Green)
6. Test indicator (Green)
5. Power indicator (Green)
4. Lockout indicator (Red)
3. ON/OFF-state indicator (Green/Red)
2. Stable-state indicator (Green)
1. Top-beam-state indicator (Blue)
4. Lockout indicator (Red)
3. ON/OFF-state indicator (Green/Red)
2. Stable-state indicator (Green)
1. Top-beam-state indicator (Blue)
10. Bottom-beam-state indicator (Blue)
9. External device monitoring indicator (Green)
8. Interlock indicator (Yellow)
7. Internal error indicator (Red)
6. Configuration indicator (Green)
5. Communication indicator (Green)
 Easy Type
 Basic Type
