F3SJ-E/B
User’s Manual
Chapter1 Internal (LED) Indicator Display Pattern
Overview and Specifications
E
Emitter
*1. The Easy Type does not have muting/override and series connection functions.
Receiver
*1. The Easy Type does not have muting/override and series connection functions.
*2.
It turns ON when there is an external device monitoring input regardless of the availability of the external device monitoring.
No. Internal indicator
Easy
Type
Basic
Type
ON Blinking
1 Top-beam-state indicator TOP *1
Turns ON when the top beam is
receiving light.
Blinks during muting/override, or
when cap error or connection
error occurs.*1
2 Stable-state indicator STB
Turns ON when incidence level is
170% or more of the output ON
threshold.
Blinks when the safety output is
turned OFF due to disturbance
light or vibration.
3 ON/OFF-state indicator
ON
OFF
Green: Turns ON when safety
output is ON.
Red: Turns ON when safety
output is OFF.
Red: Blinks when the F3SJ-E/B
enters a lockout due to a
safety output error.
4 Lockout indicator LOCKOUT
Turns ON when the F3SJ-E/B
enters a lockout on the receiver.
Blinks when the F3SJ-E/B enters
a lockout on the emitter.
5 Power indicator POWER
Turns ON while the power of the
emitter is ON.
Blinks when the F3SJ-E/B enters
a lockout due to power voltage/
noise.
6 Test indicator TEST –
Blinks when external test is being
performed.
7 Muting error indicator
MUTING
ERROR
– –
Blinks during a muting error.*1
For details, refer to
Muting Error Indication
in Chapter 6:
Troubleshooting on page
121 .
8 Muting input 1 indicator MUTE1 –
Turns ON when muting input 1 is
ON under the muting system.
–
9 Muting input 2 indicator MUTE2 –
Turns ON when muting input 2 is
ON under the muting system.
–
10 Bottom-beam-state indicator BTM *1
Turns ON when the bottom beam
is receiving light.
Blinks during muting/override.*1
No. Internal indicator
Easy
Type
Basic
Type
ON Blinking
1 Top-beam-state indicator TOP *1
Turns ON when the top beam is
receiving light.
Blinks during muting/override, or
when cap error or connection
error occurs.*1
2 Stable-state indicator STB
Turns ON when incidence level
is 170% or more of the output
ON threshold.
Blinks when the safety output is
turned OFF due to disturbance
light or vibration.
3 ON/OFF-state indicator
ON
OFF
Green: Turns ON when safety
output is ON.
Red: Turns ON when safety
output is OFF.
Red: Blinks when the F3SJ-E/B
enters a lockout due to a
safety output error.
4 Lockout indicator LOCKOUT
Turns ON when the F3SJ-E/B
enters a lockout on the emitter.
Blinks when the F3SJ-E/B enters
a lockout on the receiver.
5 Communication indicator COM
Turns ON when communication
between emitter and receiver is
established.
Blinks when the F3SJ-E/B enters
lockout due to a communication
error between receiver and
emitter.
6 Configuration indicator CFG –
Blinks when the F3SJ-E/B enters
lockout due to a model type error
between receiver and emitter.
7 Internal error indicator INTERNAL –
Blinks when the F3SJ-E/B enters
a lockout due to an internal error.
8 Interlock indicator
INT
-LK
–
Turns ON when the F3SJ-E/B is
in interlock state.
Blinks when the F3SJ-E/B enters
a lockout due to a wiring error.
9
External device monitoring
indicator
EDM –
Turns ON when an input is given
to external device monitoring
input. *2
Blinks when the F3SJ-E/B enters
a lockout due to an external
device monitoring error.
10 Bottom-beam-state indicator BTM *1
Turns ON when the bottom beam
is receiving light.
Blinks during muting/override.*1
To Next Page
