Chapter2 Description of Functions
F3SJ-E/B
User’s Manual
System Configuration and Functions
Lockout Reset Function
When the cause of the lockout is removed, you can release the lockout by using either of the following
methods. *1
•Cycle the power back ON
•Reset input
Resetting methods differ as follows depending on the system used.
*1. When there is an input wiring error at startup, a lockout reset does not work. Fix the wiring error
and then turn ON the power again.
Easy Type
Basic Type (basic system)
Basic Type (muting system)
System Lockout reset
Easy Type
Apply a voltage of Vs-3 V to Vs to the test input line (black) for 1 s or longer, and then
open the input line or apply 0 V to 1/2 Vs again.
Basic Type (basic system)
Manual reset
Apply a voltage of Vs-3 V to Vs to the reset input line (yellow) for 1 s or longer, and
then open the input line or apply 0 V to 1/2 Vs again.
Basic Type (basic system)
Auto reset
Open or apply 0 V to 1/2 Vs to the reset input line (yellow) for 1 s or longer, and then
apply a voltage of Vs-3 V to Vs again.
Basic Type (muting system)
To Next Page
