Chapter6 Troubleshooting
Appendix
E
Emitter
Receiver
Test indicator (Green)
Power indicator (Green)
Lockout indicator (Red)
ON/OFF-state indicator (Green/Red)
Stable-state indicator (Green)
Top-beam-state indicator (Blue)
Bottom-beam-state indicator (Blue)
Lockout indicator (Red)
ON/OFF-state indicator (Green/Red)
Stable-state indicator (Green)
Top-beam-state indicator (Blue)
Bottom-beam-state indicator (Blue)
Internal error indicator (Red)
Configuration indicator (Green)
Communication indicator (Green)
Emitter
Receiver
Bottom-beam-state indicator (Blue)
Muting input 2 indicator (Green)
Muting input 1 indicator (Green)
Muting error indicator (Green)
Test indicator (Green)
Power indicator (Green)
Lockout indicator (Red)
ON/OFF-state indicator (Green/Red)
Stable-state indicator (Green)
Top-beam-state indicator (Blue)
Lockout indicator (Red)
ON/OFF-state indicator (Green/Red)
Stable-state indicator (Green)
Top-beam-state indicator (Blue)
Bottom-beam-state indicator (Blue)
External device monitoring indicator (Green)
Interlock indicator (Yellow)
Internal error indicator (Red)
Configuration indicator (Green)
Communication indicator (Green)
•Easy Type
•Basic Type
