Omron fh series Hardware Manual

3 Configuration
3 - 42
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
Camera Cable for FZ-S Camera Series
Name
Model of
Sensor
Controller
Length
Digital CCD Camera (Standalone)
0.3 megapixel camera 2 megapixel camera 5 megapixel camera
FZ-S/SC FZ-S2M/SC2M FZ-S5M2/SC5M2
Camera cable
Right-angle Camera
cable
FZ-VS3
FZ-VSL3
2 m ccc
3 m ccc
5 m ccc
10 m cc ×
Bend resistant Cam-
era cable
Bend resistant
Right-angle Camera
cable
FZ-VSB3
FZ-VSLB3
2 m ccc
3 m ccc
5 m ccc
10 m
cc ×
Long-distance Cam-
era cable
Long-distance
Right-angle Camera
cable
FZ-VS4
FZ-VSL4
15 m
cc ×
Name
Model of
Sensor
Controller
Length
Small Digital CCD
Camera (Standalone)
Flat type/pen type
High-speed digital
CCD Camera (Stand-
alone)
Intelligent Compact
Digital CMOS Camera
FZ-SF/SFC
FZ-SP/SPC
FZ-SH/SHC FZ-SQ

Camera cable
Right-angle Camera
cable
FZ-VS3
FZ-VSL3
2 m ccc
3 m ccc
5 m ccc
10 m ccc
Bend resistant Cam-
era cable
Bend resistant
Right-angle Camera
cable
FZ-VSB3
FZ-VSLB3
2 m ccc
3 m ccc
5 m ccc
10 m
ccc
Long-distance Cam-
era cable
Long-distance
Right-angle Camera
cable
FZ-VS4
FZ-VSL4
15 m
ccc
