3-2 Camera
3
3-2-6 Intelligent Compact Digital CMOS Camera: FZ-S camera Series
3-2-6 Intelligent Compact Digital CMOS Camera: FZ-S camera Series
Specification
Model FZ-SQ010F FZ-SQ050F FZ-SQ100F FZ-SQ100N
Image elements CMOS color image elements (1/3-inch equivalent)
Color/Monochrome Color
Effective pixels 752 (H) × 480 (V)
Imaging area H × V
(opposing corner)
4.51 × 2.88 (5.35 mm)
Pixel size 6.0 (ȝm) × 6.0 (ȝm)
Shutter function 1/250 to 1/32,258
Partial function 8 to 480 lines
Frame rate
(Image Acquisition
Time)
60 fps (16.7 ms)
Field of vision 7.5 × 4.7 to 13 × 8.2
mm
13 × 8.2 to 53 × 33
mm
53 × 33 to 240 × 153
mm
29 × 18 to 300 × 191
mm
Installation distance 38 to 60 mm 56 to 215 mm 220 to 970 mm 32 to 380 mm
LED class
*1
*1. Applicable standards: IEC62471-2
Risk Group2
Ambient temperature
range
Operating: 0 to 50°C
Storage: -25 to 65°C
Ambient humidity
range
Operating and storage: 35 to 85%RH (with no condensation)
Weight Approx. 150 g Approx. 140 g
Accessories Mounting bracket (FQ-XL)
Polarizing filter attachment (FQ-XF1)
Instruction Sheet
Warning label

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
