3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-4 Lens
3
3-4-7 High-resolution Telecentric Lens for C-mount Lens for 2/3-inch Image Sensor
FZ-S, FZ-SH, FZ-S2M, FZ-S5M2, or FH-S are recommended.
3-4-7 High-resolution Telecentric Lens for C-mount Lens for 2/3-inch
Image Sensor
Specification
Model
*1
3Z4S-LE
VS-TCH05
-65

3Z4S-LE
VS-TCH05
-110

3Z4S-LE
VS-TCH1
-65

3Z4S-LE
VS-TCH1
-110

Optical magnification (±5%) 0.5 × 1.0 ×
Field of
view
(±5%)
(V × H)
(mm)
FH-SC/-SM 1/3 inch equiva-
lent
9.6 × 7.2 4.8 × 3.6
FH-SC2M/-SM2M 2/3 inch equiva-
lent
22.4 × 12 11.2 × 6.0
FZ-SC/-S 1/3 inch equiva-
lent
9.6 × 7.2 4.8 × 3.6
FZ-SC2M/-S2M 1/1.8 inch equiva-
lent
14.0 × 10.6 7.0 × 5.3
FZ-SC5M/-S5M 2/3 inch equiva-
lent
16.8 × 14.2 8.4 × 7.1
WD (mm)
*2
75.3 110.8 68.8 110.3
Effective FNO 9.42 9.49 9.94 10.49
Depth of field (mm)
*3
33.040.80.84
Resolution (ȝm)
*4
12.43 12.9 6.71 6.99
TV distortion 0.02% 0.02% 0.01% 0.02%
Maximum sensor size 2/3 inch 2/3 inch
Model
*1
3Z4S-LE
VS-TCH1.5
-65

3Z4S-LE
VS-TCH1.5
-110

3Z4S-LE
VS-TCH2
-65

3Z4S-LE
VS-TCH2
-110

Optical magnification (±5%) 1.5 × 2.0 ×
Field of
view
(±5%)
(V × H)
(mm)
FH-SC/-SM 1/3 inch equiva-
lent
3.2 × 2.4 2.4 × 1.8
FH-SC2M/-SM2M 2/3 inch equiva-
lent
7.5 × 4.0 5.6 × 3.0
FZ-SC/-S 1/3 inch equiva-
lent
3.2 × 2.4 2.4 × 1.8
FZ-SC2M/-S2M 1/1.8 inch equiva-
lent
4.7 × 3.5 3.5 × 2.7
FZ-SC5M/-S5M 2/3 inch equiva-
lent
5.6 × 4.7 4.2 × 3.6
WD (mm)
*2
65 110.8 65 110.8
Effective FNO 11.8 11.97 13.6 13.5
Depth of field (mm)
*3
0.4 0.43 0.3 0.27
Resolution (ȝm)
*4
5.24 5.33 4.53 4.53
TV distortion 0.01% 0.02% 0.03% 0.03%
Maximum sensor size 2/3 inch 2/3 inch
