Omron fh series Hardware Manual

5 - 35
5 Setup and Wiring
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-8 Installation in a Control Panel
5
5-8-1 All Series
5-8 Installation in a Control Panel
When the Sensor Controller is being installed in a cabinet or control panel, be sure to provide proper
ambient conditions as well as access for operation and maintenance.
Precautions for Safe Use
Installation Environment
• Do not use the product in areas where flammable or explosive gases are present.
• Install the product so that air can flow freely through its cooling vents.
• Clean the vent hole and discharge opening to prevent dust or particles from blocking them.
Blocked cooling vents or discharge opening of the fan increasing heat inside, causing mal-
function of the product.
• Do not install the product close to high-voltage devices and power devices in order to secure
the safety of operation and maintenance.
• Make sure to tighten all installation screws securely.
Accessibility for Operation and Maintenance
• Do not apply torsion stress to the cable. It may damage the cable.
• Secure the minimum bending radius of the cable. Otherwise the cable may be damaged.
