6 - 3
6 I/O Interface
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
6-1 Parallel Interface
6
6-1-2 FH-1000/FH-3000 Series
Parallel interface are common NPN/PNP type. An appropriate wiring is required according on the exter-
nal device.
Encoder interface (open corrector type) is also included.
Encoder interface (open corrector type) is ENCTRIG_A*, ENCTRIG_B*, and ENCTRIG_Z*.
Wire the pins to Encoder appropriately.
• Specifications differ by number of pins
• Encoder interface (open corrector type) is ENCTRIG_A*(8 pins,11pins), ENCTRIG_B* (12 to 13pins,
or ENCTRIG_Z*' (4 to 5pin). The frequency response of Encoder interface (open corrector type) is 4
KHz.
z
[Input]
Applicable signals/
• No.14 pin:
Connect the COMIN1 terminal when using these signals.
• No.37 to 46 pins:
Connect the COMIN2 terminal when using these signals.
6-1-2 FH-1000/FH-3000 Series
Interface Specification
Item Specifications
Input voltage 12 to 24 VDC ±10%
ON current
*1
*1. ON current and ON voltage:
Those mean the current or voltage to turn ON from OFF. The ON voltage value is the potential difference
between COMIN and each input terminal
5 mA min.
ON voltage
*1
8.8 V min.
OFF current
*2
*2. OFF current and OFF voltage:
Those mean the current or voltage to turn OFF from ON. The OFF voltage value is the potential difference
between COMIN and each input terminal
0.5 mA max.
OFF voltage
*2
1.1 V max.
ON delay 5 ms max.
OFF delay 0.7 ms max.

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
