3 Configuration
3 - 32
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-2-5 Small Digital CCD Cameras: FZ-S Camera Series
Specification
Model FZ-SF FZ-SFC FZ-SP FZ-SPC
Image elements Interline transfer reading all pixels, CCD image elements (1/3-inch equivalent)
Color/Monochrome Monochrome Color Monochrome Color
Effective pixels 640 (H) × 480 (V)
Imaging area H × V
(opposing corner)
4.8 × 3.6 (6.0 mm)
Pixel size 7.4 (ȝm) × 7.4 (ȝm)
Shutter function Electronic shutter; select shutter speeds from 20 ȝm to 100 ms
Partial function 12 to 480 lines
Frame rate
(Image Acquisition
Time)
80 fps (12.5 ms)
Lens mounting Special mount (M10.5 P0.5)
Field of vision, instal-
lation distance
Selecting a lens according to the field of vision and installation distance
Ambient temperature
range
Operating of camera amp: 0 to 50°C
Operating of camera head: 0 to 45°C
Storage: -25 to 65°C (with no icing or condensation)
Ambient humidity
range
Operating and storage: 35 to 85%RH (with no condensation)
Minimum bending
radius between cam-
era head and camera
amplifier
12.7mm
Weight Approx. 150 g
Accessories Instruction Sheet, installation bracket,
Four mounting brackets (M2 × 4)
Instruction Sheet
To Next Page
