3 - 73
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-7 LCD and Cable
3
z
Monitor Cable: FZ-VM
*1. Cable: 2m and 5m
z
DVI-I -RGB Conversion Connector: FH-VMRGB
Dimensions
(Unit: mm)
221.5
+0.5
-0mm
Panel cut drawing
161.5
+0.5
-0mm
(103.5)
(130)
(172)
230
(85.5)
(38)
(12.5)
(129.4)
171
(90)
75
4-M4
75
26
(31.5)
40
Mountable board thickiness:1.6 to 4.8
(173.4)
(185)
161
220
(6)
29.8
15.6
33.7
L
*1
30±5
30±5
2-15 pin rectangular connector
(Unit: mm)
5 dia.
(19.2 dia.)
63.8
15.740
54 4.9
(Unit: mm)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
