Omron fh series Hardware Manual

6 - 53
6 I/O Interface
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
6-4 Ethernet Interface
6
6-4-2 FH-L Series
Describes the connection processing to connector hood of shield as the following. The connection pro-
cessing is changed according to the transfer speed.
• 10BASE-T/100BASE-TX
Connects the shield of its both ends to each of connector hoods. Connects the shield of only one side
of switching hub to connector hoods.
• 1000BASE-T
Connects the shield of its both ends to each of connector hoods.
Wiring

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
