3 Configuration
3 - 16
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
*1. Existing third class grounding
Usage Envi-
ronment
Ambient temperature range Operating: 0°C to 45°C (When the built-in FAN is set to slow
rotation.)
Operating: 0°C to 50°C (When the built-in FAN is set to fast
rotation.)
Storage: -20 to +65°C
Ambient humidity range Operating and Storage: 35 to 85%RH (with no condensation)
Ambient atmosphere No corrosive gases
Vibration tolerance Oscillation frequency: 10 to 150 Hz
Half amplitude: 0.1 mm
Acceleration: 15 m/s
2
Sweep time: 8 minute/count
Sweep count: 10 times
Vibration direction: up and down/front and behind/left and right
Shock resistance Test sort1
Impact force: 150 m/s
2
Test direction: up and down/front and behind/left and right
Noise
immunity
Fast Transient Burst DC power
Direct infusion: 2kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms, Period: 300ms
Grounding
Type D grounding (100ȍ or less grounding resistance)
*1
External
Features
Dimensions 260 mm × 308 mm × 83 mm 260 mm × 308 mm × 104 mm
Weight Approx. 3.2 kg Approx. 3.4 kg
Degree of protection IEC60529 IP20
Case material ABS
Sensor Controller Series FZ5-600 series
Type Standard Controller
Sensor Controller Model FZ5-600 FZ5-605 FZ5-600-10 FZ5-605-10
