3 - 37
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-2 Camera
3
3-2-6 Intelligent Compact Digital CMOS Camera: FZ-S camera Series
z
Wide View
• Long-distance: FZ-SQ100F
• Short-distance: FZ-SQ100N
*1. The mounting brackets can be connected to either side.
Additional Information
We have the 2D CAD data or 3D CAD data.
You can download CAD data from www.fa.omron.co.jp.
1
(49)
338
(94.8)
44
Mounting Bracket *1
1/4-20UNC Depth: 6
Four, M4 Depth: 6
46
45
67
Optical
axis
8
94.8 32
20
Polarizing
Filter Attachment
20
(25)
38
42
20±0.1
Two, 4.5 dia.
Mounting Hole Dimensions
Tightening torque: 1.2 N·m
(Unit: mm)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
