Ordering Information
■ List of Models
Advanced Unit
Note: 1. The OFF-delay time can be set in 16 steps as follows:
T15: 0/0.2/0.3/0.4/0.5/0.6/0.7/1/1.5/2/3/4/5/7/10/15 s
T150: 0/10/20/30/40/50/60/70/80/90/100/110/120/130/140/150 s
2. The OFF-delayed output becomes an instantaneous output by setting the OFF-delay time to 0 s.
3. P channel MOS FET transistor output
4. PNP transistor output
Basic Unit
Note: 1. P channel MOS FET transistor output
2. PNP transistor output
Non-Contact Door Switch Controller (Controllers for D40A)
Note: 1. P channel MOS FET transistor output
2. The OFF-delayed output becomes an instantaneous output by setting the OFF-delay time to 0 s.
3. PNP transistor output
4. The OFF-delay time can be set in 16 steps as follows:
0/0.2/0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.4/1.8/2.0/2.5/3.0 s
Safety Guard Switching Unit
Note: 1. The OFF-delay time can be set in 16 steps as follows:
T15: 0/0.2/0.3/0.4/0.5/0.6/0.7/1/1.5/2/3/4/5/7/10/15 s
2. The OFF-delayed output becomes an instantaneous output by setting the OFF-delay time to 0 s.
3. P channel MOS FET transistor output
4. PNP transistor output (except for the external indicator outputs, which are P channel MOS FET transistor outputs)
Expansion Unit
Note: 1. PNP transistor output
2.
The OFF-delay time is synchronized to the OFF-delay time setting in the connected Unit (G9SX-AD-
@
, G9SX-ADA-
@
, G9SX-NSA
@
and G9SX-GS-
@
).
Safety outputs
(solid state) (See note 3.)
Auxiliary outputs
(solid state)
(See note 4.)
Logical AND connection
No. of input
channels
Max. OFF-
delay time
(See note 1.)
Rated
voltage
Terminal block type Model
Instantaneous
OFF-delayed
(See note 2.)
Inputs Outputs
3
(Semiconductor)
2
(Semiconductor)
2
(Semiconductor)
1
(Semiconductor)
1
(Semiconductor)
1 or 2
channels
15 s
24 VDC
Screw terminals G9SX-AD322-T15-RT
Spring-cage terminals G9SX-AD322-T15-RC
150 s
Screw terminals G9SX-AD322-T150-RT
Spring-cage terminals G9SX-AD322-T150-RC
2
(Semiconductor)
2
(Semiconductor)
2
(Semiconductor)
15 s
Screw terminals G9SX-ADA222-T15-RT
Spring-cage terminals G9SX-ADA222-T15-RC
150 s
Screw terminals G9SX-ADA222-T150-RT
Spring-cage terminals G9SX-ADA222-T150-RC
Safety outputs
(solid state) (See note 1.)
Auxiliary outputs
(solid state)
(See note 2.)
Logical AND
connection
No. of input
channels
Rated
voltage
Terminal block type Model
Instantaneous OFF-delayed Inputs Outputs
2
(Semiconductor)
---
2
(Semiconductor)
02
1 or 2
channels
24 VDC
Screw terminals G9SX-BC202-RT
Spring-cage terminals G9SX-BC202-RC
Safety outputs
(See note.1)
Auxiliary outputs
(See note 3.)
Logical AND
connection
input
Logical AND
connection
output
Max. OFF-
delay time
(See note 4.)
Rated
voltage
Terminal block type Model
Instantaneous
OFF-delayed
(See note 2.)
2
(Semiconductor)
0
2
(Semiconductor)
11
---
24 VDC
Screw terminals G9SX-NS202-RT
Spring-cage terminals G9SX-NS202-RC
2
(Semiconductor)
3.0 s
Screw terminals G9SX-NSA222-T03-RT
Spring-cage terminals G9SX-NSA222-T03-RC
Safety outputs (See note 3.)
Auxiliary outputs
(See note 4.)
Logical AND connection
Max. OFF-
delay time
(See note 1.)
Rated
voltage
Terminal block
type
Model
Instantaneous
OFF-delayed
(See note 2.)
Inputs Outputs
2 (semiconductor) 2 (semiconductor) 6 (semiconductor) 1 (semiconductor) 1 (semiconductor) 15 s
24
VDC
Screw terminals G9SX-GS226-T15-RT
Spring-cage
terminals
G9SX-GS226-T15-RC
Safety outputs
Auxiliary outputs
(See note 1.)
OFF-delay time Rated voltage Terminal block type Model
Instantaneous OFF-delayed
4 PST-NO (contact) ---
1 (semiconductor)
---
24 VDC
Screw terminals G9SX-EX401-RT
Spring-cage terminals G9SX-EX401-RC
--- 4 PST-NO (contact) (See note 2.)
Screw terminals G9SX-EX041-T-RT
Spring-cage terminals G9SX-EX041-T-RC
