2. Characteristics
2-1 Advanced Unit/Basic Unit
Note: 1. When two or more Units are connected by logical AND, the operating time and response time are the sum total of the operating times and response
times, respectively, of all the Units connected by logical AND.
2. Represents the operating time when the safety input turns ON with all other conditions set.
3. Represents the operating time when the logical AND input turns ON with all other conditions set.
4. For the G9SX-@-RT (with screw terminals) only.
Item Model G9SX-AD322-@/ADA222-@ G9SX-BC202-@
Over-voltage category (IEC/EN 60664-1) II
Operating time (OFF to ON state)
(See note 1.)
50 ms max. (Safety input: ON) (See note 2.)
100 ms max. (Logical AND connection input:
ON) (See note 3.)
50 ms max. (Safety input: ON)
Response time (ON to OFF state)
(See note 1.)
15 ms max.
ON-state residual voltage 3.0 V max. (safety output, auxiliary output)
OFF-state leakage current 0.1 mA max. (safety output, auxiliary output)
Maximum wiring length of safety input
and logical AND input
100 m max.
(External connection impedance: 100 Ω max. and 10 nF max.)
Reset input time (Reset button pressing
time)
100 ms min.
Accuracy of OFF-delay time Within ± 5% of the set value ---
Insulation
resistance
Between logical AND
connection terminals, and
power supply input terminals
and other input and output
terminals connected
together
20 MΩ min. (at 100 VDC)
---
Between all terminals
connected together and DIN
rail
20 MΩ min. (at 100 VDC)
Dielectric
strength
Between logical AND
connection terminals, and
power supply input terminals
and other input and output
terminals connected
together
500 VAC for 1 min
---
Between all terminals
connected together and DIN
rail
500 VAC for 1 min
Vibration resistance Frequency: 10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude)
Shock
resistance
Destruction 300 m/s
2
Malfunction 100 m/s
2
Ambient temperature −10 to 55°C (no icing or condensation)
Ambient humidity 25% to 85%
Terminal tightening torque (See note 4.) 0.5 N·m
Weight Approx. 200 g Approx. 125 g
