7 Digital I/O Slave Unit
7 - 54
GX-series EtherCAT Slave Unit User’s Manual
 Output section
Notes For the I/O power supply current value to V and G terminals ,refer to "A-5 I/O Power Supply Current" in
Page A - 79.
Item
Specification
GX-MD1618 GX-MD1628
Output capacity 8 points
Rated output current 0.5 A/output, 2.0 A/common
Residual voltage
1.2 V max.
(0.5 ADC, between each output terminal
and the G terminal)
1.2 V max.
(0.5 ADC, between each output terminal
and the V terminal)
Leakage current 0.1 mA max.
ON delay 0.5 ms max.
OFF delay 1.5 ms max.
Number of circuits per
common
8 points/common
Isolation method Photocoupler isolation
I/O power supply method Supply by I/O power supply
Output device supply
current
100 mA/point
I/O power supply current
consumption
10 mA max. (for 20.4 to 26.4-VDC power supply voltage)
Error Mode Output Select either hold or clear.
