8
Analog I/O Slave Unit
8 - 22
GX-series EtherCA
T Slave Unit User
’s Manual
Precautions fo
r Correct Use
Do not wire NC terminals.
Internal circuits diagram
Wiring diagram
V+
I+
AG
V
−
Analog GND
250
Ω
510 k
Ω
510 k
Ω
0 V
0 V
Short-circuit *
V
oltage input
Current input
Short-circuit the “V positive” terminal and “I positive” terminal at current input.
Use the attached short-circuit metal fixture to short-circuit these terminals.
*
