8 - 21
8 Analog I/O Slave Unit
GX-series EtherCAT Slave Unit User’s Manual
8-6 Overview of Each Slave Unit Type
8
8-6-1 4-point Input Slave Unit GX-AD0471
• Input range setting switches
Set input range by combination of individual DIP switches.
To enable settings of these switches, it is necessary to turn Pin8 (input range setting method) ON in
advance.
Precautions for Correct Use
• When setting a range with these switches, the same input ranges are set for inputs CH1 and
CH2 as well as inputs CH3 and CH4, respectively. To set a different range for inputs CH1 to
CH4, use the SDO communications to make the settings.
• Pin7 must be used in the OFF state.
• To set a range using these switches, make sure to turn Pin8 ON. If it is turned OFF, the DIP
switch settings will not be reflected.
• The settings of this switch are read only once when the power is turned ON.
• Setting of input CH1/CH2 range (Pin1 to Pin3)
• Setting of input CH3/CH4 range (Pin4 to Pin6)
Precautions for Correct Use
Do not set the DIP switches or Pins other than as specified in the tables above.
Pin No. Setting Specification
1
Setting of input CH1/CH2 range (common)
Set by combination of DIP switches (see the
next table)
2
3
4
Setting of input CH3/CH4 range (common)5
6
7 Always OFF
Make sure to keep it OFF.
The operation cannot be guaranteed when it is
set to ON.
8 Input range setting method
OFF: Setting by SDO communications
ON: Setting by the switches (Pin1 to Pin6)
Input range Pin1 Pin2 Pin3
0 to 5 V OFF OFF OFF
1 to 5 V ON OFF OFF
0 to 10 V OFF ON OFF
−10 to +10 V ON ON OFF
4 to 20 mA OFF OFF ON
Input range Pin4 Pin5 Pin6
0 to 5 V OFF OFF OFF
1 to 5 V ON OFF OFF
0 to 10 V OFF ON OFF
−10 to +10 V ON ON OFF
4 to 20 mA OFF OFF ON
