9 - 27
9 Encoder Input Slave Unit
GX-series EtherCAT Slave Unit User’s Manual
9-4 Specifications for Each Slave Unit
9
9-4-2 Line Driver Input Type GX-EC0241
• Terminal block
CH
Terminal
block
number
Terminal name Contents
CH1
CH2
1RSV -
2RSV -
3RSV -
4RSV -
5RSV -
6RSV -
7 LA1/LA2 Latch A input
8 LB1/LB2 Latch B input
9 RST1/RST2 Reset input
10 V1 Internal circuit/sensor power supply input
11 V1 (Spare)
12 A+ Phase A input (+)
13 B+ Phase B input (+)
14 Z+ Phase Z input (+)
15 V1 (Spare)
16 V1 Sensor power supply output
17 V1 Sensor power supply output
18 V1 Sensor power supply output
19 G1 Internal circuit/sensor power supply input
20 G1 (Spare)
21 A- Phase A input (-)
22 B- Phase B input (-)
23 Z- Phase Z input (-)
24 G1 (Spare)
25 G1 Sensor power supply output
26 G1 Sensor power supply output
27 G1 Sensor power supply output
