Omron GX-ID1611 User Manual

A - 55
A Appendix
GX-series EtherCAT Slave Unit User’s Manual
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific Objects
The contents of Error Status for Ports 3 and 4 are given below. The status can be accessed either as
WORD data or BOOL data.
3002 hex Port3_4 I/O Port Error Status
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port3_4 I/O Port Error Status
Range: − Unit: − Default: 0000 hex Attribute: −
Size: 2 bytes (U16) Access: RO PDO map: Not possible
3003 hex Port5_6 I/O Port Error Status
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port5_6 I/O Port Error Status
Range: − Unit: − Default: 0000 hex Attribute: −
Size: 2 bytes (U16) Access: RO PDO map: Not possible
Bit Meaning
Default
value
Data range Unit Data type Access
I/O allo-
cation
Data
attribute
0 Port 3 IO-Link Communications
Error Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
1 Port 3 IO Short Detected Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
2 Port 3 Verification Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
3 Port 3 Device I/O Size Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
4 Port 3 Device Error-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
5 Port 3 Device Warning-level
Event Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
6 Port 3 PDO Mapping Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
8 Port 4 IO-Link Communications
Error Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
9 Port 4 IO Short Detected Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
10 Port 4 Verification Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
11 Port 4 Device I/O Size Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
12 Port 4 Device Error-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
13 Port 4 Device Warning-level
Event Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
14 Port 4 PDO Mapping Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
