The meanings of the set values for the Device Verification Settings are as follows:
3201 hex IO-Link Device Verification Setting
Sub-index 0: Number of entries
Range: − Unit: − Default: 08 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port1 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 2: Port2 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 3: Port3 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 4: Port4 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 5: Port5 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 6: Port6 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 7: Port7 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Sub-index 8: Port8 Device Verification Setting
Range: 00 to 02 hex Unit: − Default: 00 hex Attribute: R
Size: 1 byte (U8) Access: RW PDO map: Not possible
Set value Meaning
00 hex Do not check.
01 hex Devices are verified for the vendor ID, device ID, and IO-Link revision.
02 hex Devices are verified for the vendor ID, device ID, IO-Link revision, and serial number.
